Akuvox ACR-CID13 Desktop Fingerprint Capture Device
The Akuvox ACR-CID13 is a compact USB desktop fingerprint scanner used to enroll fingerprint credentials into an access control system. Its semiconductor press-type sensor captures a fingerprint image in under 0.25 seconds at 508dpi, with strong adaptability to both dry and wet fingers, and connects plug and play to Windows or macOS.
Key Specifications
Core Features
Technical Specifications
| Category | Specification |
|---|---|
| Model | ACR-CID13 |
| Sensor Type | Semiconductor, press-type |
| Image Resolution | 256 x 360 pixels |
| Resolution (dpi) | 508 |
| Image Distortion Calibration | <=2% |
| Fingerprint Image Capture Time | <=0.25s |
| Fingerprint Capture Window | 13.5mm x 19.1mm |
| Effective Detection Area | 12.8mm x 18mm |
| Communication Interface | USB 2.0 |
| Operating Voltage | DC 5.0V ±0.5V |
| Maximum Current | <60mA VDD (excluding indicator light) |
| Indicator Light | Red / Green |
| Dimensions | 76.07mm x 56.33mm x 48.23mm |
| Operating Temperature | -10°C to 55°C (±2°C) |
| Storage Temperature | -40°C to 60°C (±2°C) |
| Relative Humidity | 20~93% RH |
| Operating Systems | Windows, macOS |
Similar products
Questions and answers
No questions about this product yet. Ask ours first, and a licensed installer will answer.
Get a quote for this product
Prefer the full form?
Tell us about the property and we will plan the cabling, power and recording with you. Mention the product above.
The full quote form opens as you scroll here.
Frequently Asked Questions
It's a USB desktop fingerprint scanner used to enroll fingerprint credentials into an access control system from a computer, rather than at a door terminal.
Yes. It's built with strong adaptability to both dry and wet fingers, which is a common weak point for lower-quality fingerprint sensors.
A fingerprint image is captured in 0.25 seconds or less.
No. The ACR-CID13 is plug and play over USB 2.0, and is supported on both Windows and macOS.
A built-in red/green LED gives visual feedback on the capture status during fingerprint enrollment.
