Akuvox S532 Hybrid Video Door Phone with Induction Loop
A sophisticated Linux-based hybrid video door phone that bridges analog and IP technologies. Features a built-in IP-to-analog conversion module for seamless upgrades of traditional intercom systems without extensive rewiring. Equipped with a 2.8-inch LCD display, 2MP wide-angle camera, and multiple access control methods including PIN, RFID, NFC, and Bluetooth.
$808.00
Seamless System Upgrade
Built-in IP-to-analog conversion module allows modernization of traditional intercom systems without expensive rewiring or complete system replacement.
Comprehensive Entrance Coverage
2MP camera with 130° horizontal and 90° vertical viewing angles provides wide coverage of entry points, enhanced by smart motion detection with precision alerting.
Flexible Access Control
Multiple authentication methods including PIN codes, RFID cards (13.56MHz & 125kHz), NFC, and Bluetooth cater to diverse user preferences and security requirements.
Rugged & Reliable Design
IP66 rating for water/dust resistance and IK08 impact protection ensure reliable performance in harsh environmental conditions and high-traffic areas.
Multi-Residential Buildings
Apartment complexes and condominiums upgrading from traditional analog intercoms to modern IP systems with mobile app integration.
Office Complexes
Corporate offices requiring secure access control with multiple authentication methods and integration with existing security systems.
Retrofit Projects
Existing buildings where complete rewiring is impractical or cost-prohibitive, needing a bridge between old and new technologies.
Commercial Spaces
Retail stores, warehouses, and industrial facilities needing durable, weather-resistant access control with video verification.
Retrofit solution: The S532 is ideal for upgrading existing analog intercom systems in apartments, offices, and commercial buildings. Its hybrid design eliminates the need for complete rewiring while adding modern IP capabilities like mobile app integration and smart access control.
Key Specifications
Display
2.8-inch color LCD with numeric keypad and extra function buttons
Camera
2MP sensor with automatic lighting, 130° horizontal / 90° vertical viewing angle
Power
802.3at Power-over-Ethernet (PoE+) or external power supply
Protection Rating
IP66 weatherproof, IK08 vandal resistance
Access Methods
PIN codes, RFID cards (13.56MHz & 125kHz), NFC, Bluetooth (BLE)
Relays & I/O
2 output relays for door opener, 4 inputs, RS485, Wiegand port, analog audio output
Operating Temp
-40°C to +60°C (operating), -40°C to +70°C (storage)
Connectivity
Ethernet RJ45 (10/100Mbps), Bluetooth, TF card slot, audio/video interface for analog systems
Core Features
Seamless System Upgrade: Built-in IP-to-analog conversion module allows modernization of traditional intercom systems without expensive rewiring or complete system replacement.
Comprehensive Entrance Coverage: 2MP camera with 130° horizontal and 90° vertical viewing angles provides wide coverage of entry points, enhanced by smart motion detection with precision alerting.
Flexible Access Control: Multiple authentication methods including PIN codes, RFID cards (13.56MHz & 125kHz), NFC, and Bluetooth cater to diverse user preferences and security requirements.
Rugged & Reliable Design: IP66 rating for water/dust resistance and IK08 impact protection ensure reliable performance in harsh environmental conditions and high-traffic areas.
Multi-Residential Buildings: Apartment complexes and condominiums upgrading from traditional analog intercoms to modern IP systems with mobile app integration.
Office Complexes: Corporate offices requiring secure access control with multiple authentication methods and integration with existing security systems.
Retrofit Projects: Existing buildings where complete rewiring is impractical or cost-prohibitive, needing a bridge between old and new technologies.
Commercial Spaces: Retail stores, warehouses, and industrial facilities needing durable, weather-resistant access control with video verification.
Technical Specifications
| Category | Specification |
|---|---|
| Brand | Akuvox |
| Model / SKU | akuvox-s532-2-8-keypad-linux-video-door-phone-hybrid |
| Display | 2.8-inch color LCD with numeric keypad and extra function buttons |
| Camera | 2MP sensor with automatic lighting, 130° horizontal / 90° vertical viewing angle |
| Power | 802.3at Power-over-Ethernet (PoE+) or external power supply |
| Protection Rating | IP66 weatherproof, IK08 vandal resistance |
| Access Methods | PIN codes, RFID cards (13.56MHz & 125kHz), NFC, Bluetooth (BLE) |
| Relays & I/O | 2 output relays for door opener, 4 inputs, RS485, Wiegand port, analog audio output |
| Operating Temp | -40°C to +60°C (operating), -40°C to +70°C (storage) |
| Connectivity | Ethernet RJ45 (10/100Mbps), Bluetooth, TF card slot, audio/video interface for analog systems |
