Akuvox A08S Smart Access Control Terminal with HID iClass Module
A sophisticated multi-method access control terminal featuring HID iClass compatibility, QR code, Bluetooth, PIN, and RFID authentication. Built with an aluminum alloy frame and toughened glass front panel, offering IP65 & IK09 ratings for maximum durability in demanding environments.
$567.00
Multi-Method Flexibility
Supports QR codes for visitor access, Bluetooth for mobile users, PIN for employees, and RFID cards including HID iClass for enterprise security systems.
Enterprise-Grade Durability
IP65 rating ensures protection against dust and water jets, while IK09 impact resistance withstands vandalism in high-traffic public areas.
High-Capacity Management
Handles up to 20,000 user credentials and logs 100,000 access events, making it suitable for large office buildings, campuses, and residential complexes.
Seamless Integration
Compatible with Wiegand and OSDP protocols for easy integration into existing access control systems and security infrastructure.
Corporate Offices
Secure entry to office buildings with employee RFID cards, visitor QR codes, and PIN access for different security zones.
Multi-Residential Buildings
Apartment complexes and condominiums requiring durable, weather-resistant access control with multiple authentication options.
Educational Institutions
Schools and universities needing high-capacity systems for students, staff, and visitors with detailed access logging.
Industrial Facilities
Factories, warehouses, and industrial parks requiring rugged access control that withstands harsh environmental conditions.
Enterprise-grade security: The A08S supports dual authentication (combining two access methods) for enhanced security. Its slim 26.7mm profile makes it ideal for installation on door frames and tight spaces in commercial and residential buildings.
Key Specifications
Protection Rating
IP65 (dust-tight, water jet protected), IK09 (high impact resistance)
Access Methods
QR Code, Bluetooth (BLE), PIN code, RFID (13.56MHz & 125kHz, HID iClass compatible)
Memory Capacity
20,000 card capacity, 100,000 event log storage
Power Options
12V DC connector or Power over Ethernet (PoE) capable
I/O & Connectivity
1 relay output, 2 inputs, Wiegand, RS485, RJ45 Ethernet (10/100Mbps)
Operating Temp
-20°C to +55°C (operating), -30°C to +70°C (storage)
Construction
Aluminum alloy frame with toughened glass front panel
Installation
Flush-mounted or wall-mounted, compact 50 x 140 x 26.7mm dimensions
Core Features
Multi-Method Flexibility: Supports QR codes for visitor access, Bluetooth for mobile users, PIN for employees, and RFID cards including HID iClass for enterprise security systems.
Enterprise-Grade Durability: IP65 rating ensures protection against dust and water jets, while IK09 impact resistance withstands vandalism in high-traffic public areas.
High-Capacity Management: Handles up to 20,000 user credentials and logs 100,000 access events, making it suitable for large office buildings, campuses, and residential complexes.
Seamless Integration: Compatible with Wiegand and OSDP protocols for easy integration into existing access control systems and security infrastructure.
Corporate Offices: Secure entry to office buildings with employee RFID cards, visitor QR codes, and PIN access for different security zones.
Multi-Residential Buildings: Apartment complexes and condominiums requiring durable, weather-resistant access control with multiple authentication options.
Educational Institutions: Schools and universities needing high-capacity systems for students, staff, and visitors with detailed access logging.
Industrial Facilities: Factories, warehouses, and industrial parks requiring rugged access control that withstands harsh environmental conditions.
Technical Specifications
| Category | Specification |
|---|---|
| Brand | Akuvox |
| Model / SKU | akuvox-a08s-smart-access-control-terminal-hid-iclass-module-pin-bluetooth-qr-code |
| Protection Rating | IP65 (dust-tight, water jet protected), IK09 (high impact resistance) |
| Access Methods | QR Code, Bluetooth (BLE), PIN code, RFID (13.56MHz & 125kHz, HID iClass compatible) |
| Memory Capacity | 20,000 card capacity, 100,000 event log storage |
| Power Options | 12V DC connector or Power over Ethernet (PoE) capable |
| I/O & Connectivity | 1 relay output, 2 inputs, Wiegand, RS485, RJ45 Ethernet (10/100Mbps) |
| Operating Temp | -20°C to +55°C (operating), -30°C to +70°C (storage) |
| Construction | Aluminum alloy frame with toughened glass front panel |
| Installation | Flush-mounted or wall-mounted, compact 50 x 140 x 26.7mm dimensions |
