AJAX TurretCam HL 8MP 2.8mm Black | 4K AI Hybrid Illumination IP Camera
The AJAX TurretCam HL 8MP 2.8mm Black is a professional wired 4K AI-powered IP security camera featuring hybrid IR and white-light illumination up to 50 metres. In night mode, the camera uses infrared illumination and automatically activates white light when motion is detected, providing colour footage of important events. Delivers 3840 × 2160 resolution at up to 20 FPS, a 2.8mm lens with 110° horizontal viewing angle, 120 dB True WDR, AI-powered recognition of people, vehicles and animals, H.265/H.264 video compression, built-in microphone, PoE/12V power, and IP65/IK08 protection for indoor and outdoor installations.
Price on Request
SKU: 126264 · In Stock · TurretCam HL 8MP · Black
TurretCam HL
Hybrid Illumination 50m
IR and white-light LEDs both reach up to 50 metres. In night mode the camera uses IR illumination, automatically activating white light when motion is detected — providing colour footage of important events.
4K 8MP · 120 dB True WDR
3840 × 2160 px at up to 20 FPS with 120 dB True WDR — evidence-grade 4K footage with wide dynamic range for challenging lighting environments.
AI Object Recognition
Identifies people, vehicles, and animals to filter out irrelevant motion events and deliver meaningful alerts through the Ajax ecosystem.
IP65 + IK08 · Black
Full dust and water jet protection plus IK08 impact resistance for demanding environments. Black finish suits dark surfaces and discreet installations.
HL vs standard TurretCam 8MP: The TurretCam HL (126264) adds hybrid illumination (IR + white light to 50m) over the standard model (64928, IR-only to 35m). Both are 4K 8MP with True WDR and AI detection. Choose the HL for full-colour night footage. White version: SKU 126265. 4mm variants: SKU 126266 (Black) / 126267 (White). Contact us if you need help choosing.
Key Specifications
Camera Sensor
8MP CMOS, 1/2.7″ type
Resolution
3840 × 2160 px (4K) @ 20 FPS
Lens
Fixed 2.8mm f/1.6 · 110° FOV
Illumination
Hybrid IR + white light · 50m
AI Recognition
People, vehicles, animals
Dynamic Range
120 dB True WDR
Power
PoE 802.3af/at · 12V DC
Protection
IP65 / IK08
| Specification | Details |
|---|---|
| Model | AJAX |
| Product Name | TurretCam HL 8MP 2.8mm Black |
| Type | Wired AI-powered IP security camera with hybrid illumination |
| Colour | Black |
| Image Sensor | 8MP CMOS, 1/2.7″ type |
| Maximum Resolution | 3840 × 2160 px (4K Ultra HD) |
| Frame Rate | Up to 20 FPS |
| Lens Focal Length | 2.8mm |
| Maximum Aperture | f/1.6 |
| Horizontal FOV | 110° |
| Vertical FOV | 56° |
| Diagonal FOV | 126° |
| Minimum Illumination (Colour) | 0.005 lx |
| Illumination Type | Hybrid — IR LED + white light LED |
| IR Illumination Range | Up to 50m |
| White Light Range | Up to 50m |
| Lighting Control | Automatic intelligent IR/white LED intensity adjustment |
| Dynamic Range | 120 dB True WDR |
| AI Recognition | People, vehicles, animals |
| Motion Detection | Software image-frame analysis |
| Video Compression | H.265 / H.264 |
| Video Protocol | JetSparrow |
| Audio | Built-in digital microphone |
| Audio Codecs | G.711-ULAW, G.711-ALAW, G.726, G.722 |
| Storage | microSD up to 256GB / Ajax NVR |
| Network Interface | 1 × RJ-45 10/100 Mbps Ethernet |
| ONVIF | Supported |
| Power Supply | PoE 802.3af/at · 12V DC ±20% |
| Protection Rating | IP65 |
| Impact Resistance | IK08 |
| Dimensions | 103 × 98 × 98mm |
| Weight | 475g |
| Operating Temperature | −30°C to +60°C |
| Operating Humidity | Up to 90% |
| White Variant SKU | AJAX |
| 4mm Black Variant SKU | AJAX |
| 4mm White Variant SKU | AJAX |
| Standard TurretCam 8MP Black SKU | AJAX |
| Warranty | 24 months |
Frequently Asked Questions
The TurretCam HL (126264) adds hybrid illumination — both IR and white-light LEDs reaching up to 50 metres — over the standard TurretCam 8MP (64928) which uses IR-only illumination up to 35 metres. Both models are 4K 8MP with True WDR, AI detection, and IP65/IK08 protection. Choose the HL if full-colour night footage is required.
Hybrid illumination combines IR LEDs (invisible infrared light) and white LEDs (visible white light) in the same camera. In night mode the camera uses infrared illumination and automatically activates white light when motion is detected, providing colour footage of important events.
The white-light LED illumination reaches up to 50 metres. The IR illumination also reaches up to 50 metres. Both are subject to intelligent automatic intensity adjustment based on scene conditions.
Yes. The camera supports PoE (802.3af/at) with a maximum power consumption of up to 7.5–8.5W depending on configuration. A single Ethernet cable carries both data and power. 12V DC (±20%) is also supported as an alternative power source.
The camera supports microSD cards up to 256GB. A V30 or faster card is recommended for 4K recording. The card is not included. For multi-camera centralised recording, an Ajax NVR is the recommended solution.
The 2.8mm model (126264) provides a wider ~110° horizontal field of view, better for broad-area coverage. The 4mm model (126266) provides a narrower field of view, better suited to focused monitoring of corridors, driveways, and specific zones. Both share the same 4K resolution, hybrid illumination, and IP65/IK08 protection.
Yes. The white version is AJAX TurretCam HL 8MP 2.8mm White — identical specifications in a white enclosure.
Yes. Professional installation ensures optimal camera placement, correct PoE cabling, NVR configuration, Ajax ecosystem integration, and correct configuration of hybrid illumination settings. Sipko Security provides full supply, installation, and commissioning across Melbourne.
4K Full-Colour Night Surveillance for Melbourne Properties
The AJAX TurretCam HL 8MP 2.8mm Black combines 4K Ultra HD video, AI object recognition, 120 dB True WDR, and 50m hybrid IR + white-light illumination in a rugged IP65/IK08 black enclosure. Designed for residential, commercial, retail, and industrial surveillance where detailed day and night coverage is required.
