AJAX TurretCam HL 8MP 2.8mm Black | 4K AI Hybrid Illumination IP Camera

Name: AJAX TurretCam HL 8MP 2.8mm Black | 4K AI Hybrid-Illumination IP Camera
Brand: AJAX
SKU: 126264

The AJAX TurretCam HL 8MP 2.8mm Black is a professional wired 4K AI-powered IP security camera featuring hybrid IR and white-light illumination up to 50 metres. In night mode, the camera uses infrared illumination and automatically activates white light when motion is detected, providing colour footage of important events. Delivers 3840 × 2160 resolution at up to 20 FPS, a 2.8mm lens with 110° horizontal viewing angle, 120 dB True WDR, AI-powered recognition of people, vehicles and animals, H.265/H.264 video compression, built-in microphone, PoE/12V power, and IP65/IK08 protection for indoor and outdoor installations.

Hybrid Illumination 4K · 8MP AI Detection IP65 / IK08

Price on Request SKU: 126264 · In Stock · TurretCam HL 8MP · Black

TurretCam HL

Call Now: 0406 432 691 Request a Quote Contact Us View Full Specs

Hybrid Illumination 50m IR and white-light LEDs both reach up to 50 metres. In night mode the camera uses IR illumination, automatically activating white light when motion is detected — providing colour footage of important events.

4K 8MP · 120 dB True WDR 3840 × 2160 px at up to 20 FPS with 120 dB True WDR — evidence-grade 4K footage with wide dynamic range for challenging lighting environments.

AI Object Recognition Identifies people, vehicles, and animals to filter out irrelevant motion events and deliver meaningful alerts through the Ajax ecosystem.

IP65 + IK08 · Black Full dust and water jet protection plus IK08 impact resistance for demanding environments. Black finish suits dark surfaces and discreet installations.

HL vs standard TurretCam 8MP: The TurretCam HL (126264) adds hybrid illumination (IR + white light to 50m) over the standard model (64928, IR-only to 35m). Both are 4K 8MP with True WDR and AI detection. Choose the HL for full-colour night footage. White version: SKU 126265. 4mm variants: SKU 126266 (Black) / 126267 (White). Contact us if you need help choosing.

Key Specifications

Camera Sensor

8MP CMOS, 1/2.7″ type

Resolution

3840 × 2160 px (4K) @ 20 FPS

Lens

Fixed 2.8mm f/1.6 · 110° FOV

Illumination

Hybrid IR + white light · 50m

AI Recognition

People, vehicles, animals

Dynamic Range

120 dB True WDR

Power

PoE 802.3af/at · 12V DC

Protection

IP65 / IK08

Specification	Details
Model	AJAX
Product Name	TurretCam HL 8MP 2.8mm Black
Type	Wired AI-powered IP security camera with hybrid illumination
Colour	Black
Image Sensor	8MP CMOS, 1/2.7″ type
Maximum Resolution	3840 × 2160 px (4K Ultra HD)
Frame Rate	Up to 20 FPS
Lens Focal Length	2.8mm
Maximum Aperture	f/1.6
Horizontal FOV	110°
Vertical FOV	56°
Diagonal FOV	126°
Minimum Illumination (Colour)	0.005 lx
Illumination Type	Hybrid — IR LED + white light LED
IR Illumination Range	Up to 50m
White Light Range	Up to 50m
Lighting Control	Automatic intelligent IR/white LED intensity adjustment
Dynamic Range	120 dB True WDR
AI Recognition	People, vehicles, animals
Motion Detection	Software image-frame analysis
Video Compression	H.265 / H.264
Video Protocol	JetSparrow
Audio	Built-in digital microphone
Audio Codecs	G.711-ULAW, G.711-ALAW, G.726, G.722
Storage	microSD up to 256GB / Ajax NVR
Network Interface	1 × RJ-45 10/100 Mbps Ethernet
ONVIF	Supported
Power Supply	PoE 802.3af/at · 12V DC ±20%
Protection Rating	IP65
Impact Resistance	IK08
Dimensions	103 × 98 × 98mm
Weight	475g
Operating Temperature	−30°C to +60°C
Operating Humidity	Up to 90%
White Variant SKU	AJAX
4mm Black Variant SKU	AJAX
4mm White Variant SKU	AJAX
Standard TurretCam 8MP Black SKU	AJAX
Warranty	24 months

Frequently Asked Questions

The TurretCam HL (126264) adds hybrid illumination — both IR and white-light LEDs reaching up to 50 metres — over the standard TurretCam 8MP (64928) which uses IR-only illumination up to 35 metres. Both models are 4K 8MP with True WDR, AI detection, and IP65/IK08 protection. Choose the HL if full-colour night footage is required.

Hybrid illumination combines IR LEDs (invisible infrared light) and white LEDs (visible white light) in the same camera. In night mode the camera uses infrared illumination and automatically activates white light when motion is detected, providing colour footage of important events.

The white-light LED illumination reaches up to 50 metres. The IR illumination also reaches up to 50 metres. Both are subject to intelligent automatic intensity adjustment based on scene conditions.

Yes. The camera supports PoE (802.3af/at) with a maximum power consumption of up to 7.5–8.5W depending on configuration. A single Ethernet cable carries both data and power. 12V DC (±20%) is also supported as an alternative power source.

The camera supports microSD cards up to 256GB. A V30 or faster card is recommended for 4K recording. The card is not included. For multi-camera centralised recording, an Ajax NVR is the recommended solution.

The 2.8mm model (126264) provides a wider ~110° horizontal field of view, better for broad-area coverage. The 4mm model (126266) provides a narrower field of view, better suited to focused monitoring of corridors, driveways, and specific zones. Both share the same 4K resolution, hybrid illumination, and IP65/IK08 protection.

Yes. The white version is AJAX TurretCam HL 8MP 2.8mm White — identical specifications in a white enclosure.

Yes. Professional installation ensures optimal camera placement, correct PoE cabling, NVR configuration, Ajax ecosystem integration, and correct configuration of hybrid illumination settings. Sipko Security provides full supply, installation, and commissioning across Melbourne.

What’s Included With Professional Installation

Optimal Placement

We assess your property and position the camera for the best coverage angle, illumination range, and glare avoidance.

Correct PoE Cabling

Properly run and terminated PoE cabling for reliable power and data, concealed neatly where possible.

NVR Configuration

Full setup of your Ajax NVR or storage, recording schedules, and playback access configured correctly.

Ajax Ecosystem Integration

Camera linked into your Ajax system and app so alerts, AI detection, and footage all work together.

Hybrid Illumination Setup

Correct configuration of IR and white-light thresholds so night footage triggers exactly as intended.

Full Supply & Commissioning

Sipko Security supplies, installs, and commissions the complete system across Melbourne, ready to use.
