AJAX MountCam A2 White - 174mm Wall Mount for Varifocal Cameras
Key Specifications
Core Features
Technical Specifications
| Category | Specification |
|---|---|
| Product name | AJAX MountCam A2 |
| Type | 174 mm wall mount for a wired security IP camera, with an adapter for a camera with a motorized varifocal lens |
| Compatible cameras | BulletCam, BulletCam HL, Superior BulletCam HLVF, DomeCam Mini, DomeCam Mini HL, DomeCam HLVF, Superior DomeCam HLVF, TurretCam, TurretCam HL, TurretCam HLVF, Superior TurretCam HLVF, as listed by Ajax |
| Not compatible | BulletCam HLVF is not compatible with MountCam mounts |
| Key features | Strap slots to secure the mount to a pole, holding screw to secure the mount to a bracket |
| Installation features | Pre-drilled fixing points, space for organising cables inside the mount, captive screws |
| Use | Indoor and outdoor |
| Dimensions | 86 x 136 x 174 mm |
| Weight | 630 g |
| Operating temperature | -40 to +60 degrees C |
| Colour | White (this listing is the white model). Ajax also makes it in black |
| Complete set | MountCam A2, installation template, installation kit, quick start guide |
| Sold | Separately from Ajax cameras |
| Warranty | 24 months, as published by Ajax Systems |
Downloads
- Technical specifications Web page · ajax.systems · Ajax Systems
- User manual Web page · ajax.systems · Ajax Systems
- EU Declaration of Conformity (MountCam series) PDF · ajax.systems · Ajax Systems, PDF
Documents are published by the manufacturer and open in a new tab. Specifications can change between production batches, so check the document for your exact model.
Similar products
-
AJAX MountCam A1 Black - Professional 164MM Wall Mount IP Camera Accessory
Price on request
-
AJAX MountCam B1 Black - 237mm Extended Wall Mount
Price on request
-
AJAX MountCam B2 White - Professional 242mm Wall Mount IP Camera Accessory
Price on request
-
AJAX Ceiling Mount Bracket Black - Professional Australian Made Motion Sensor Mounting Bracket
Price on request
-
AJAX Hood for MotionProtect Outdoor
Price on request
Questions and answers
No questions about this product yet. Ask ours first, and a licensed installer will answer.
Get a quote for this product
Prefer the full form?
Tell us about the property and we will plan the cabling, power and recording with you. Mention the product above.
The full quote form opens as you scroll here.
Frequently Asked Questions
Ajax lists BulletCam, BulletCam HL, Superior BulletCam HLVF, DomeCam Mini, DomeCam Mini HL, DomeCam HLVF, Superior DomeCam HLVF, TurretCam, TurretCam HL, TurretCam HLVF and Superior TurretCam HLVF. BulletCam HLVF is not compatible with MountCam mounts. Ask us to check your exact camera before you order.
The mount features an adapter for a camera with a motorized varifocal lens, so those cameras can be fitted to the mount.
No. The MountCam A2 is sold separately from Ajax cameras.
Yes. Ajax designs it for indoor and outdoor use, with an operating range of -40 to +60 degrees C.
Yes. It has strap slots that let you secure the mount to a pole.
The MountCam A2, an installation template, an installation kit and a quick start guide.
It is a 174 mm mount. The full size is 86 x 136 x 174 mm and it weighs 630 g.
Yes. We supply and install Ajax cameras and mounts across Melbourne and the Mornington Peninsula. Request a quote and we will plan the mounting and cabling with you.
Mount Your Camera the Right Way
Getting the mount and adapter right the first time avoids re-drilling and re-cabling later. We'll confirm compatibility with your exact camera model before installation.
