AJAX Curtain Outdoor Jeweller Wireless Motion Detector
The AJAX Curtain Outdoor Jeweller is a professional-grade wireless outdoor motion detector featuring dual-technology sensors (PIR + K-band microwave), 12m detection range, pet immunity up to 100cm, IP55 weatherproof design, and up to 3 years battery life. Perfect for outdoor perimeter security, property boundaries, and comprehensive surveillance coverage.
Key Specifications
Core Features
Technical Specifications
| Category | Specification |
|---|---|
| Device Type | AJAX Curtain Outdoor Jeweller (Wireless Outdoor Motion Detector) |
| Model/SKU | AJAX |
| Sensor Technology | Dual-Technology: 2 PIR sensors + 1 K-band microwave sensor |
| Detection Range | Up to 12 meters (adjustable sensitivity) |
| Pet Immunity | Enabled up to 100cm height (small animals, pets) |
| Detection Angle | Horizontal coverage for outdoor perimeter monitoring |
| False Alarm Prevention | Dual-sensor confirmation reduces false triggers |
| Wireless Protocol | Jeweller 5.2 & Wings protocols |
| Communication Range | Up to 1,700 meters (open air, line-of-sight) |
| Frequency Band | 868 MHz (ISM Band) |
| Transmission Power | 10 mW EIRP |
| Encryption | AES-128 end-to-end encryption |
| Battery Type | 2x CR123A (3V Lithium) |
| Battery Life | Up to 3 years (typical usage) |
| Battery Monitoring | Low battery alert notification |
| Housing Material | UV-resistant plastic composite |
| Housing Color | White |
| Dimensions | Compact outdoor-rated form factor |
| IP Rating | IP55 (dust-tight, water jet resistant) |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Operating Humidity | 10% to 95% (non-condensing) |
| Weather Resistance | Rain, snow, ice, UV radiation resistant |
| Response Time | Less than 1 second motion detection |
| Hub Compatibility | AJAX hub and control panel systems |
| Installation | Wall-mounted, outdoor placement |
| Certifications | CE, RoHS compliant |
| Warranty | Standard manufacturer warranty included |
Similar products
Questions and answers
No questions about this product yet. Ask ours first, and a licensed installer will answer.
Get a quote for this product
Prefer the full form?
Tell us about the property and we will plan the cabling, power and recording with you. Mention the product above.
The full quote form opens as you scroll here.
Frequently Asked Questions
The AJAX Curtain Outdoor Jeweller is a wireless outdoor motion detector designed for perimeter security, property boundary monitoring, and outdoor surveillance enhancement. Its dual-technology sensors and 12m detection range make it ideal for gardens, driveways, property boundaries, and outdoor entry points across Melbourne properties.
The Curtain Outdoor Jeweller combines two PIR (infrared) sensors and one K-band microwave sensor. This dual approach requires both sensors to detect motion before triggering an alert, significantly reducing false alarms from weather conditions, reflections, or small movements. The dual confirmation provides professional-grade reliability.
Pet immunity mode is designed to ignore motion from small animals and pets up to 100cm in height. This prevents false alarms from dogs, cats, and wildlife moving through your monitored area, while still detecting human-sized intruders. Perfect for properties with outdoor pets or wildlife activity.
The AJAX Curtain has an adjustable detection range up to 12 meters. This covers most residential driveways, garden areas, and property boundaries. The sensitivity is adjustable, allowing you to customize coverage for your specific installation location and security needs.
Yes, absolutely. The Curtain Outdoor Jeweller is rated IP55, meaning it's fully protected against dust and water jets. The UV-resistant plastic housing withstands sun exposure, rain, snow, ice, and temperature extremes from -25°C to +60°C. It's built for Melbourne's unpredictable outdoor conditions.
The AJAX Curtain Outdoor Jeweller operates for up to 3 years on two standard CR123A lithium batteries. Battery life depends on motion frequency and detector sensitivity settings. The system provides low battery alerts via the AJAX hub so you can replace batteries before they fail.
The detector uses Jeweller and Wings wireless protocols operating on the 868 MHz frequency band with up to 1,700 meters communication range (in open air). All transmissions are encrypted with AES-128 end-to-end encryption for secure, reliable operation without interference.
The AJAX Curtain Outdoor Jeweller integrates with AJAX hub and control panel systems. It works seamlessly with AJAX security ecosystems for centralized monitoring, smart automation, and professional installation. Sipko Security can configure the complete integration for your Melbourne property.
Yes. Multiple AJAX Curtain detectors can be deployed across your property and integrated with a single AJAX hub system. This allows comprehensive perimeter coverage with centralized monitoring and automation. Sipko Security can design a multi-detector layout tailored to your property's security needs.
Sipko Security provides professional installation, configuration, and ongoing technical support for all AJAX products. We handle optimal placement, system integration, test activation, and provide you with complete documentation and training. Full warranty and after-sales support are included.
Protect Your Property's Perimeter with Professional Motion Detection
The AJAX Curtain Outdoor Jeweller combines cutting-edge dual-technology motion detection, pet immunity, and weatherproof design for comprehensive outdoor security. Perfect for residential properties, commercial facilities, and any Melbourne installation requiring reliable outdoor perimeter monitoring.
