UNV NVR502-16E-IM-G 16‑Channel 4K Network Video Recorder | Melbourne
A powerful 16‑channel 1U NVR supporting Ultra H.265/H.265/H.264 compression and 32 MP recording.
Ideal for medium‑to‑large surveillance systems in Melbourne. Features smart analytics (face detection, LPR, video metadata),
2× Gigabit Ethernet ports, and SeekFree technology for smooth playback with third‑party cameras.
A$660 +GST
Professional NVR – final pricing depends on HDD configuration and installation scope.
Price on application
Ultra H.265+
Save bandwidth and storage with the latest compression, supports up to 32 MP resolution.
2× Gigabit Ethernet
Dual NICs for multi‑access, load balancing or fault tolerance – reliable connectivity.
Smart analytics
Face detection, LPR, video metadata, and intrusion prevention – on‑board or via cameras.
SeekFree & ANR
Smooth playback with third‑party cameras and automatic network failover protection.
Melbourne installs: Ideal for retail, offices, and residential estates. We supply, rack‑mount, configure network/storage, and integrate with your UNV or third‑party IP cameras.
Keywords:
UNV NVR502-16E-IM-G
· 16‑channel NVR · 4K recorder · Ultra H.265 · face detection LPR · Melbourne
Technical Specifications
Quick Specs
Video Input
16‑ch IP, up to 32 MP per channel
Decoding
Ultra H.265/H.265/H.264; 2×32MP@30 or 16×1080P@30 (smart off)
Bandwidth
192 Mbps incoming / 192 Mbps outgoing
Network
2× RJ45 GigE, multi‑access/load balance/fault‑tolerance
Recording
32 MP … CIF; 32‑ch concurrent playback, 16‑ch local sync playback
Storage
2× SATA, up to 24 TB each, RAID 1 support
I/O & Alarms
4‑ch alarm in, 1‑ch out, RS485, 1×USB2.0 + 1×USB3.0
Smart Features
Face detection/recognition, LPR, video metadata, SIP, ANR, SeekFree
Full NDAA‑compliant model. Dimensions: 380×322.4×53 mm (1U), weight 1.87 kg (without HDD).
Why Choose This UNV NVR in Melbourne
Built for performance
1
Future‑proof compression
Ultra H.265 saves up to 50% storage vs H.264 – ideal for longer retention and lower bandwidth.
2
Powerful smart analytics
On‑board face, vehicle, and metadata analysis – reduces server load and enables fast search.
3
Dual Gigabit Ethernet
Separate camera and client networks, or link aggregation for higher throughput and redundancy.
4
SeekFree & ANR
Smooth playback with third‑party cameras; network failover ensures continuous recording.
Our Seamless Installation Process
Step‑by‑step
1
Site survey
Check rack space, network switch capacity, and camera compatibility (UNV / ONVIF).
2
Mount & connect
Rack‑mount the NVR, connect to PoE switch, install HDDs, and apply power.
3
Configure system
Network settings, camera addition, recording schedules, smart event rules, and user access.
4
Test & handover
Verify recording, playback, remote viewing, and provide client walkthrough.
Tip: We recommend using UNV or compatible ONVIF cameras to unlock full smart analytics and SeekFree benefits.
Request Your Free Installation Quote
Fast response
Tell us about your project: number of cameras, desired HDD capacity, and whether you need help with camera selection. We’ll provide a clear quote and scope for Melbourne metro areas.
Frequently Asked Questions
10 FAQs
The NVR502-16E-IM-G supports up to 32 MP per channel, with decoding capability for 2 channels of 32 MP @30 fps simultaneously.
Yes, it supports ONVIF Profile S and many third‑party brands. SeekFree technology enhances playback compatibility.
SeekFree allows smooth timeline playback even with third‑party cameras by using a smart indexing technology – no more jerky video when searching.
It has two SATA III interfaces, each supporting up to 24 TB (total up to 48 TB). RAID 1 is available for redundancy.
Yes, it supports face detection/recognition, LPR (license plate recognition), video metadata, and intrusion prevention – either via smart cameras or on‑board analysis (depending on mode).
You can separate camera and client traffic, use link aggregation for higher throughput, or set up fault‑tolerance for network redundancy.
Yes, via UNV’s UCode app or web browser (plugin‑free for Chrome, Edge, Firefox). It also supports cloud upgrade.
Automatic Network Replenishment – if the network is disconnected, the camera stores video locally and the NVR retrieves it once the connection is restored, ensuring no gaps.
Yes, the NVR502-E-IM-G series is NDAA compliant, suitable for US federal projects and many commercial tenders.
We rack‑mount the NVR, install HDDs, connect to your network, add cameras, configure recording and smart events, and provide a full handover.
Price Check Snapshot
Market reference
The UNV NVR502-16E-IM-G is priced A$660 (excl. GST) for the base unit without HDDs or installation. Contact us with your camera count and storage needs, and we’ll provide a competitive quote. If you have a like‑for‑like quote from another supplier, we’ll do our best to match it.
